From Brickearths, to Bricks, to Palaeolithic Archaeology

There is an important connection between brickmaking and the Palaeolithic in Barnham, as explored by Peter Hoare.

Barnham Brickyard (Credit: Euston Estate)

The archaeological site at East Farm is located on the floor of an overgrown pit set amongst arable fields and farm buildings on the edge of Barnham village. Today, we are confronted with a hole in the ground measuring ca 130 m west to east, 70 m north to south and 6 m deep.

Rumour has it that brickearth (a portmanteau term) was quarried here as early as the eighteenth century. A small part of the history of Barnham brickmaking is recorded in the sole surviving ledger, covering the period 22 August 1895–30 December 1912, held by the Euston Estate (East Farm is just one of several properties on the ca 2530 ha estate). So perhaps more than 150 years of brickmaking are unrecorded. Brickearth digging took place seasonally until the 1930s to supply the Barnham brickyard.

No photographs of raw material extraction can be traced, and the only known surviving photograph of the brickyard, which was demolished many years ago, is a small, poor-quality print held by the Euston Estate (reproduced left).

There were two principal types of clay- and silt-rich brickearth: one produced white bricks (Unit 5c of the stratigraphic story), the other red ones (Unit 7). Bricks and related products were made for a great variety of uses on the Euston Estate, but the brickyard also operated on a commercial basis, supplying Lord Iveagh on the neighbouring Elveden Estate, as well as numerous local builders and others.

Apart from the single Euston Estate ledger, no account of brickmaking at Barnham appears to have survived. Peter Minter, owner of the famous Bulmer Brickyard, Essex, has told us that he believes Barnham bricks would have been produced in a similar way to that of other eastern counties brickyards, including his own.

Re-exposing old clay pits by removing backfill: spade marks left by clay digging

The highly calcareous brickearth from Barnham Area III would have been tempered with sand or less carbonate-rich material; the amount of space available to dry the bricks before firing would have limited the rate of production; and eighteenth-century kilns would have held between 4000 and 5000 bricks. Each man is likely to have made ca 1000 bricks per day in the nineteenth century; it is now ca 500 at Bulmer.

Although the records are incomplete, the peak period of brickearth quarrying and brickmaking probably occurred at the start of the twentieth century. The south and west wings of Euston Hall were destroyed by fire on 5 April 1902, the fourth occasion on which the premises were badly damaged by fire. Rebuilding took place with little delay. Brickyard ledger entries for ‘Mr Heath Euston Hall’ start on 8 June 1903 and end on 15 April 1912, but 89% of the material was produced in the second half of 1903 and in 1905. The wings were rebuilt on the same plan, consuming, amongst other items, 322,975 red bricks, 3500 white bricks, 650 plain tiles, 150 paving bricks and 130 glazed pantiles. The total cost was £577 12s 5p, equivalent to ca £68,000 in 2019. The south wing and most of the west wing were pulled down by the tenth Duke of Grafton in 1952!

Excavations in Area III reveal old clay pits.

Brickearth extraction was responsible for revealing the Palaeolithic archaeology for which East Farm is renowned. The earliest evidence for the discovery of artefacts is of ‘… two flint implements …’ found in 1882, but they probably came from the gravel pit to the east of the village. Other late nineteenth-century finds are likely to have been of an opportunistic nature, some discovered in the wash-pit at the brickyard.

Barnham artefacts purchased from East Farm in ca 1905 included two twisted ovates, one of which is said to have been used by the brickearth diggers to clean their spades! By the time of the first formal excavation at Barnham in the 1930s, the brickearth diggers had produced numerous sections for archaeologists to explore. But that’s another story.

Further Reading

There is just one brief description of brickearth extraction at Barnham East Farm in Ashton, N.M., Lewis, S.G. & Parfitt, S.A. 1998. Excavations at the Lower Palaeolithic site at East Farm, Barnham, Suffolk 1989–94. British Museum Occasional Paper 125, p. 292.

Readers might like to refer to The Brickmaker’s Tale (The Bulmer Brick and Tile Co, 2014), Peter Minter’s account of his family’s brickyard.
